HONGDUI DJ11S 精密 面取りカンナ 木工用トリマープレーン
税込み価格 配送料は購入手続き時に計算されます。
HONGDUIのDJ11Sは、表面の幾何学形状に一切の妥協を許さない木工家たちのための、決定版となるエッジプロファイリング・ソリューションです。洗練されたデュアルシャフト（2軸）の微調整機構を備えたこのプレーン（カンナ）は、面取り（チャムファー）やベベル加工の寸法を常に完璧かつ均一に保ちます。DJ11Sは、木目の美しい移行（滑らかな木肌のつながり）を実現するために不可欠な、揺るぎない剛性の土台と永続的な切れ味を提供します。シャープなエッジの面取りであれ、再現性の高い幾何学的ディテールの加工であれ、HD-DJ11Sはプロ仕様の効率性を備えつつ、流れるような滑らかさと精密なベベル加工をお届けします。
* **実質12刃分！革新的な超硬インサート**：超硬インサート3個（1個につき4面：直角2面＋R面2面、合計12の切削面）を搭載し、頻繁な刃交換の手間を大幅に削減します。本体装着済み2個＋予備1個が付属し、内蔵ストレージスロットにスッキリ収納可能です。
* **2-in-1効率的な面取り設計**：独創的な4面一体型刃設計により、刃の切り替えが非常にスムーズ。45°直線面取りとR丸面取りの両方に対応し、作業時間を大幅に短縮（半減）します。
* **高精度なデュアルスケール深さ調整**：操作しやすい大型「+-」ノブで切り込み深さを自在にコントロール。ミリ（mm）とインチ（inch）の両対応目盛りが刻印されており、単位換算の手間なく毎回正確なカットが可能です。
* **多用途な面取り能力**：45度の直線面取り（角面取り）およびR3（1/8インチ）の丸面取り（R面取り）に最適。DIY愛好家からプロの木工家まで満足できる仕上がりを提供します。
* **紛失を防ぐ便利な予備パーツ固定構造**：本体の右上部に予備スクリュー（ネジ）2個を直接装着・保持できる設計を採用。パーツの紛失による作業中断を防ぎ、快適なワークフローを約束します。
* モデル：DJ11S
* 外形寸法：約 15.5 × 6.5 × 4.5 cm
* 材質：アルミニウム合金
* 本体重量：約 0.65 kg
* クランプ（加工）範囲：0.1mm〜6mmの精密な面取り・ベベル加工に対応
* デュアルシャフト面取りカンナ（本体） × 1
* プレインストール済み超硬ブレード × 2
* トルクスレンチ × 1
【警告】本製品は、癌、先天異常、その他の生殖障害を引き起こすことがカリフォルニア州で知られているクロムなどの化学物質にさらされる可能性があります。
詳細については、www.P65Warnings.ca.gov をご覧ください。
FAQ
Check out the most common questions our customers asked.
What is the primary purpose of the DJ11S Chamfer Plane?
Unlike a standard block plane, the DJ11S is specifically designed to create uniform chamfers (flat bevels) or rounded edges on the corners of your workpiece. Its V-shaped base ensures the tool remains perfectly centered on the edge, eliminating the guesswork of holding a plane at a 45-degree angle.
What materials are used in its construction?
The body is made from thickened aluminum alloy, providing a balance of durability and lightness for one-handed operation. The blades are crafted from tungsten steel (carbide) or high-carbon steel, designed to hold an edge much longer than standard utility blades.
Does it have a built-in level?
Yes, the DJ11S features an integrated horizontal bubble level. This helps you ensure that the tool is held perfectly flat during operation, which is especially useful when working on larger surfaces or ensuring consistency across multiple edges.
How many different blade profiles are available?
One of the key features of the DJ11S is its modularity. It typically supports multiple interchangeable cutters:
Flat Blade: For standard 45° chamfers.
Radius Blades: Available in various sizes (e.g., R1, R2, R3) for creating different rounded edge profiles.
Specialty Blades: Depending on the kit, it may include double-rounded or pointed profiles for decorative joinery.
How do I change the blades?
The blades are secured with a single hex bolt. To change them, simply loosen the bolt with the included wrench, slide out the current blade, and drop in the new profile. The tool is designed so that the blades seat in a fixed position, requiring minimal recalibration after a swap.
How do I adjust the depth of the cut?
The DJ11S features a knurled adjustment knob at the top. Rotating the knob moves the blade assembly up or down. Because the blade is held at a fixed angle, this adjustment directly controls the width of the chamfer or the depth of the radius.
What is the maximum cutting depth?
The depth is typically adjustable from 0mm to 10mm, though for the smoothest results in hardwoods, it is recommended to take several shallow passes rather than one deep cut.
How do I ensure the chamfer is the same size on all four edges of a board?
Once you achieve the desired depth on your first edge, the locking mechanism keeps the blade at that exact height. As long as the knob isn't moved, the V-guide ensures every subsequent edge will be identical.
Can the blades be sharpened?
Tungsten steel blades are extremely hard and difficult to sharpen by hand. However, because they are modular, they are designed to be replaceable. When a blade becomes dull or nicked, most users find it more efficient to replace it with a fresh cutter to maintain precision.
How do I keep the tool sliding smoothly?
Keep the V-groove base clean of pitch and resin buildup. Periodically wipe the base with a bit of denatured alcohol. Applying a light coat of paste wax to the aluminum base will significantly reduce friction and prevent the aluminum from leaving marks on light-colored woods.
What should I do if the adjustment knob feels stiff?
Sawdust can sometimes enter the threaded adjustment column. Use a blast of compressed air to clear the mechanism. Avoid using heavy grease; a dry PTFE spray is the best choice for lubricating the internal threads without attracting more dust.
- The quality is awesome and this should last a lifetime.
- Super adjustable. You set it the way you want it, lock it in, and go to town.
- Blades come sharp out of the box, easy to dial in the depth of cut for accuracy.
IMMPRESSED.
deciding to spend this kind of money was a big decision. Im glad i did. The quality is awsome and this should last a lifetime.
This has a great weight and feel to it. Super adjustable. You set it the way you want it, lock it in, and go to town with no fears of overdoing it. Love the chamfers it makes. Gives a real finished look to all my projects.
This chamfering plane is very well made and heavy. It feel good in you hand and does a fantastic job of laying an even chamfer on all wood types. It does take some adjusting in order to work properly, so you will need to be patient with it. Also, plan on sharpening the blades, as no matter how sharp they look as feel, they will work exponentially better once you take the time to properly sharpen them by hand. Overall, a great addition to the tool box and a fantastically well made tool. Highly recommend.
Love HONGDUI tools you get what you pay for very solidly built works great I saw reviews saying not so great and I believe that's people who don't understand wood grain and wood you are not gonna find a sharper tool and if used right on your project it's awesome the round over on one side and 45 degree on the other is really nice on board extra blade nice mm and inches nice made from a block of billet aluminum sweet heavy in the hand it says nice tool markings are clear I love it
Another high quality tool from Hongdui. I have several of there tools and I love them all. Blades come sharp out of the box, you easy to dial in the depth of cut for accuracy. Way better than using a power router.
